Ezviz C6C EZ360 HD Wi-Fi & lan Pan-Tilt IP Security Camera ( 720p )

Model Parameters

CS-CV246-B0-3B1WFR

Camera

Image Sensor CMOS 1/4" Progressive Scan CMOS

Shutter Speed Self-adaptive shutter

Lens 4mm@ F2.2, Diagonal angle: 90°

PT Angle Pan: 340°, Tilt: 120°

Lens Mount M12

Day & Night IR-cut filter with auto-switching

DNR 3D DNR

WDR Digital WDR

Compression

Video Compression H.264

H.264 Type Main profile

Video Bit Rate HD, Balanced and Smooth bit rate


Max. Resolution 1280×720

Image setting Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio)

BLC Support

Network

Storage Support Micro SD card (Max. 128G)

Smart Alarm Motion detection

Wi-Fi Pairing SmartConfig (Wi-Fi One-Key Configuration)/AP paring

Protocol EZVIZ cloud proprietary protocol

Interface Protocol EZVIZ cloud proprietary protocol

General Features Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark

Minimum Network Requirements 2M

Wi-Fi

Standard IEEE802.11b, 802.11g, 802.11n

Frequency Range 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth Supports 20MHz

Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate 11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps

General

Operating Conditions -30°C ~ 60°C, Humidity 95% or less (non-condensing)

Power Supply DC 5V±10%

Power Consumption Max. 5.5W

IR Range Max. 10 meters

Product Dimensions 87.7mm x 87.7mm x 112.7mm

Packaging Dimensions 106mm x 106mm x 190mm

Weight 256g
