Gigabyte AORUS RGB M.2 NVMe SSD 512GB

Interface

PCI-Express 3.0 x4, NVMe 1.3

Form Factor

M.2 2280

Warranty

Limited 5-years or 800TBW

NAND

3D TLC ToshiBa BiCS3

External DDR Cache

512MB

Sequential Read MB/s

Up to 3480 MB/s

Sequential Write MB/s

Up to 2000 MB/s

Random Read IOPS

up to 360K

Random Write IOPS

up to 440K

Mean time between failure (MTBF)

1.8 million hours

Power Consumption (Active)

Average : R : 5485mW ; W : 4085mW

Power Consumption (Idle)

272mW

Temperature (Operating)

0°C to 70°C

Temperature (Storage)

-40°C to 85°C

Note

* Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
* Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark v.5.1.2 and I0meter 1.1.0.
* Speeds based on internal testing. Actual performance may vary.
* TBW (Terabyte Written):Terabytes Written" is the total amount of data that can be written into an SSD before it is likely to fail.
* 1GB = 1 billion bytes. Actual useable capacity may vary.
* 5 years or 800 TBW, whichever comes first.
