Zyxel GS1350-6HP Smart Managed PoE Switch 5 Port Gigabit 802.3bt 60W

Name: Zyxel GS1350-6HP Smart Managed PoE Switch 5 Port Gigabit 802.3bt 60W
Brand: ZYXEL
SKU: supt33994-
Price: 7350 THB
Availability: InStock

7,990.00

฿ 7,350.00

ฟรี

ได้รับภายใน : 24 พ.ย. ~ 26 พ.ย., 2024

สามารถเก็บเงินปลายทางได้

การรับประกัน

การรับประกัน : มีการรับประกัน 2 ปี

คืนสินค้าภายใน 15 วัน

คุณสมบัติทั่วไป

คำอธิบายสินค้า

รายละเอียดสินค้า

คะแนนและรีวิว

Q & A

คุณสมบัติทั่วไป

สิ่งที่ให้มาในกล่อง	Zyxel GS1350-6HP Smart Managed PoE Switch 5 Port Gigabit 802.3bt 60W	MODEL	Zyxel GS1350-6HP Smart Managed PoE Switch 5 Port Gigabit 802.3bt 60W
การรับประกัน	Warranty Available	ระยะเวลาการรับประกัน	2 years

คำอธิบายสินค้า

Overview

Zyxel GS1350-6HP Smart Managed PoE Switch 5 Port Gigabit จ่ายไฟ 5 Port มาตรฐาน 802.3at/bt 60W

Mode Extended Range รองรับสาย Lan ได้สูงถึง 250 เมตร

รองรับการทำ VLAN 802.1q, RSTP

รายละเอียดสินค้า

Item	Features
5-port GbE Smart Managed PoE Switch with GbE Uplink
Switch class	Smart Managed
Total port count	6
100/1000 Mbps	5
Gigabit SFP	1
Gigabit combo (RJ-45/SFP)	-
Configurable extended range ports	5
PoE ports	5
Total PoE budget (watt)	60
PoE Standard	802.3af/at 802.3bt (port 1-2)
Switching capacity (Gbps)	12
Forwarding rate (Mpps)	8.9
Packet buffer (byte)	525 K
MAC address table	8 K
Input	52 V - 57 V DC
Max. power consumption (watt)	72
Dimensions (WxDxH)(mm/in.)	193 x 84 x 26 / 7.6 x 3.31 x1.02
Weight (kg/lb.)	0.41/0.9
Included accessories	Power adapter Wall-mount kit
Ethernet port surge protection	4 KV
Power supply surge protection: Line-GND	4 KV
Power supply surge protection: Line-Line	2 KV
Ethernet port ESD protection (air/contact)	15 KV/8 KV
Operating	Temperature -20°C to 50°C/-4°F to 122°F Humidity 5% to 95% (non-condensing)
Storage	Temperature -40°C to 70°C/-40°F to 158°F Humidity 5% to 95% (non-condensing)
MTBF (hr)	2,021,885.87
Heat dissipation (BTU/hr)	245.52
Acoustic noise @ 25°C (dBA)	0 (Fanless)
Standard Compliance	IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-Tx Ethernet IEEE 802.3ab 1000Base-T Ethernet IEEE 802.3z 1000 Base-X IEEE 802.3x flow control IEEE 802.3af PoE IEEE 802.3at PoE plus IEEE 802.3bt (GS1350-6HP) IEEE 802.3az EEE support / Green Ethernet IEEE 802.1p CoS support
Resilience and Availability	IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.3ad LACP (Max # Trunks/Links per Trunk): GS1350-6HP: 3/6GS1350-12HP: 6/8 GS1350-18HP: 8/8 GS1350-26HP: 8/8 Loop guard Dual configuration files Dual images
Traffic Control	802.1Q Static VLANs: 256 Port-based VLAN Voice VLAN MAC-based VLAN Vendor ID based VLAN VLAN Trunking LACP algorithm of source/destination IP
Security	Layer 2 MAC filtering Static MAC forwarding SSH v2 SSL Port isolation CPU protection SHA2 HTTPS Certification Login authentication by RADIUS RADIUS accounting Authorization on RADIUS Multiple RADIUS servers DHCP Snooping
Quality of Service (QoS)	802.1p queuing methods: SPQ, WRR, WFQ Storm control: broadcast, multicast, unknown unicast (DLF) Port-based rate limiting (ingress/egress) 802.3x flow control 802.1p Class of Service (SPQ, WFQ, SPQ/WFQ combination capable) DiffServ (DSCP)
Layer 2 Multicast	L2 Multicast Static L2 Multicast Forwarding IGMP snooping (v1,v2,v3) IGMP snooping normal leave IGMP snooping fast leave Configurable IGMP snooping timer and priority IGMP snooping statistics IGMP throttling IGMP filtering IGMP querier mode IGMP proxy mode & snooping mode selection
Manageability	SNMP v1,v2c, v3 SNMP trap group RMON (1,2,3,9) ICMP echo/echo reply Syslog Display port utilization IEEE 802.1AB LLDP IEEE 802.1AB LLDP-MED Custom default
PoE Management	Power-up mode selection Scheduled PoE Neighbor PD detection Auto PD recovery Continuous PoE Extended range* PoE consumption/classification modes Port PoE Priority Customizable maximum power per port PoE Wide range detection LLDP-Power via MDI * Extended range excels long range installation but the actual performance may be effected by cabling quality or IP camera’s electrical design. We recommend users to test for IOP before physical deployment. Contact Zyxel for IP camera’s interoperability report.
IPv6 Management	IPv6 over Ethernet (RFC 2464) IPv6 addressing architecture (RFC 4291) Dual stack (RFC4213) ICMPv6 (RFC4884) Path MTU (RFC 1981) Minimum Path MTU size of 1280 (RFC 5905) Encapsulation for maximum PMTU size of 1500 Neighbor Discovery (RFC4861)
Device Management	Web interface Setup Wizard Full managed CLI through Telnet/SSHv2 Management through Web, SNMP Remote firmware upgrade by FTP/Web Configuration saving and retrieving Configure clone DHCP client DHCP relay per VLAN Daylight saving NTP (IPv4/IPv6) Port mirroring Restore to last custom default
MIB	Zyxel private common MIB RFC 1066 TCP/IP-based MIB RFC 1213, 1157 SNMPv2c/v3 MIB RFC 1493 bridge MIB RFC 1643 Ethernet MIB RFC 1757 RMON group 1,2,3,9 RFC 2011, 2012, 2013 SNMPv2 MIB RFC 2233 SMIv2 MIB RFC 2358 Ethernet-like MIB RFC 2674 bridge MIB extension RFC 2819, 2925 Remote Management MIB RFC 3621 Power Ethernet MIB RFC 4293 Management Information Base (MIB) for IP RFC 4292 IP forwarding table MIB RFC 4022 management information base for transmission control protocol RFC 4113 management information base for user datagram protocol
Zyxel One Network	ZON Utility Discovery of Zyxel switches, APs and gateways Centralized and batch configurations: IP configurationIP renew Device factory reset Device reboot Device locating Web GUI access Password configuration One-click quick association with Zyxel AP Configurator (ZAC) Automatic detection of the latest firmware Displays device serial number and hardware version Cloud mode on/off option for Hybrid series devices Smart Connect Discover neighboring devices One-click remote management access to the neighboring Zyxel devices Reset neighboring devices remotely to factory defaults Power cycle neighboring powered devices (PoE switches only)
Certifications	EMC: CE, FCC, C-Tick, Class ABSMI CNS13438 Safety: LVD EN62368-1BSMI CNS14336-1 RoHS compliant
Installation Features	Ethernet port lightning surge protection Power supply lightning surge protection ESD(electrostatic discharge) protection Extended range of up to 250 meters* Fixed link speed at 10 MbpsLimited to 802.af PDs and cameras* Extended range excels long range installation but the actual performance may be effected by cabling quality or IP camera’s electrical design. We recommend users to test for IOP before physical deployment. Contact Zyxel for IP camera’s interoperability report.
